POPEDSP
DSP-4040
Professional 4-in/4-out digital loudspeaker processor for crossover, EQ, delay and system protection in sound installations.
Price on request
Chat with our expertAbout this product
The POPE Professional DSP-4040, identified in POPE documentation with the XP-4040 model designation, is a fixed-architecture digital loudspeaker processor designed for professional sound reinforcement. It provides four analog inputs and four outputs, 96 kHz processing, 32-bit floating-point DSP, equalization, crossover, delay, limiting and system presets. USB connectivity and software control make it suitable for both touring and fixed installations.
Specifications
- dsp
- 32-bit floating point
- type
- 4-input / 4-output digital signal processor
- delay
- Input 0 - 4.99 ms; output 0 - 9.99 ms
- inputs
- 4 analog inputs
- limiter
- -19 dB to 0 dB
- outputs
- 4 analog outputs
- presets
- 20
- crossover
- HPF / LPF
- rack_size
- 1U
- converters
- 24-bit AD/DA
- connectivity
- USB-B
- equalization
- 10-band PEQ and shelving filters
- dynamic_range
- 114 dB typical
- maximum_level
- +20 dBu
- sampling_rate
- 96 kHz
- input_impedance
- >10 kΩ
- output_impedance
- 50 Ω
- frequency_response
- ±0.1 dB, 20 Hz - 20 kHz
